ARRI L5-C Plus RGB LED Fresnel Light (Blue/Silver, Manual Yoke)
The ARRI L5-C Plus in blue/silver continues the evolution of ARRI’s LED Fresnel line with enhanced output, modern connectivity, and reliable color precision—all in a compact, user-friendly design. Equipped with a manual yoke and a 12° to 46° beam angle, the L5-C Plus delivers smooth flood-to-spot control ideal for studios, broadcast setups, and on-location shoots.
Building on the trusted performance of its predecessor, the Plus version features a new RGBW light engine, updated firmware, and compatibility with ARRI's SkyPanel software. It offers a 90% increase in output, delivering up to 48,900 lux at 3.3' (spot, 5600K) through its 5" Fresnel lens, all while maintaining the uniform light field ARRI is known for.
The fixture provides fully tunable white light from 2800K to 10,000K, full RGB+W color mixing, hue and saturation control, and green/magenta adjustment, with access to a wide gel library. With a CRI of 92 and TLCI of 83, the L5-C Plus ensures accurate, natural color rendering for skin tones and environments.
Control is seamless via DMX, RDM, Art-Net, sACN, or web-based interface (HTTP). The internal 100–240 VAC power supply supports global use (power cable sold separately), and the light offers USB-based firmware updates for future enhancements.
Mechanical features include dual focus knobs for precise adjustment from either side, a sliding stirrup for balance and mounting flexibility, and a strong tilt-lock for secure positioning. The fixture is backward-compatible with previous L-Series accessories and supports the SkyPanel USB remote (sold separately).
Specifications:
Output: Up to 48,900 lux at 3.3' (spot, 5600K)
Beam Angle: 12° to 46°
CCT Range: 2800K–10,000K
Dimming: 100–0%
Control Options: DMX, RDM, Art-Net, sACN, HTTP (web control)
Power Input: 100–240 VAC (onboard; cable sold separately)
Lens: 5" Fresnel
Firmware Updates: USB-compatible
Lifespan: 50,000+ hours
Daisy-Chain: Power and data capable
IP Rating: IP20
Certifications: CE, UKCA, CB, ENEC, cNRTLus, FCC, PSE
ARRI L5-C Plus RGB LED Fresnel Light (Blue/Silver, Manual Yoke)
The ARRI L5-C Plus in blue/silver continues the evolution of ARRI’s LED Fresnel line with enhanced output, modern connectivity, and reliable color precision—all in a compact, user-friendly design. Equipped with a manual yoke and a 12° to 46° beam angle, the L5-C Plus delivers smooth flood-to-spot control ideal for studios, broadcast setups, and on-location shoots.
Building on the trusted performance of its predecessor, the Plus version features a new RGBW light engine, updated firmware, and compatibility with ARRI's SkyPanel software. It offers a 90% increase in output, delivering up to 48,900 lux at 3.3' (spot, 5600K) through its 5" Fresnel lens, all while maintaining the uniform light field ARRI is known for.
The fixture provides fully tunable white light from 2800K to 10,000K, full RGB+W color mixing, hue and saturation control, and green/magenta adjustment, with access to a wide gel library. With a CRI of 92 and TLCI of 83, the L5-C Plus ensures accurate, natural color rendering for skin tones and environments.
Control is seamless via DMX, RDM, Art-Net, sACN, or web-based interface (HTTP). The internal 100–240 VAC power supply supports global use (power cable sold separately), and the light offers USB-based firmware updates for future enhancements.
Mechanical features include dual focus knobs for precise adjustment from either side, a sliding stirrup for balance and mounting flexibility, and a strong tilt-lock for secure positioning. The fixture is backward-compatible with previous L-Series accessories and supports the SkyPanel USB remote (sold separately).
Specifications:
Output: Up to 48,900 lux at 3.3' (spot, 5600K)
Beam Angle: 12° to 46°
CCT Range: 2800K–10,000K
Dimming: 100–0%
Control Options: DMX, RDM, Art-Net, sACN, HTTP (web control)
Power Input: 100–240 VAC (onboard; cable sold separately)
Lens: 5" Fresnel
Firmware Updates: USB-compatible
Lifespan: 50,000+ hours
Daisy-Chain: Power and data capable
IP Rating: IP20
Certifications: CE, UKCA, CB, ENEC, cNRTLus, FCC, PSE
ARRI L5-C Plus RGB LED Fresnel Light (Blue/Silver, Manual Yoke)
The ARRI L5-C Plus in blue/silver continues the evolution of ARRI’s LED Fresnel line with enhanced output, modern connectivity, and reliable color precision—all in a compact, user-friendly design. Equipped with a manual yoke and a 12° to 46° beam angle, the L5-C Plus delivers smooth flood-to-spot control ideal for studios, broadcast setups, and on-location shoots.
Building on the trusted performance of its predecessor, the Plus version features a new RGBW light engine, updated firmware, and compatibility with ARRI's SkyPanel software. It offers a 90% increase in output, delivering up to 48,900 lux at 3.3' (spot, 5600K) through its 5" Fresnel lens, all while maintaining the uniform light field ARRI is known for.
The fixture provides fully tunable white light from 2800K to 10,000K, full RGB+W color mixing, hue and saturation control, and green/magenta adjustment, with access to a wide gel library. With a CRI of 92 and TLCI of 83, the L5-C Plus ensures accurate, natural color rendering for skin tones and environments.
Control is seamless via DMX, RDM, Art-Net, sACN, or web-based interface (HTTP). The internal 100–240 VAC power supply supports global use (power cable sold separately), and the light offers USB-based firmware updates for future enhancements.
Mechanical features include dual focus knobs for precise adjustment from either side, a sliding stirrup for balance and mounting flexibility, and a strong tilt-lock for secure positioning. The fixture is backward-compatible with previous L-Series accessories and supports the SkyPanel USB remote (sold separately).
Specifications:
Output: Up to 48,900 lux at 3.3' (spot, 5600K)
Beam Angle: 12° to 46°
CCT Range: 2800K–10,000K
Dimming: 100–0%
Control Options: DMX, RDM, Art-Net, sACN, HTTP (web control)
Power Input: 100–240 VAC (onboard; cable sold separately)
Lens: 5" Fresnel
Firmware Updates: USB-compatible
Lifespan: 50,000+ hours
Daisy-Chain: Power and data capable
IP Rating: IP20
Certifications: CE, UKCA, CB, ENEC, cNRTLus, FCC, PSE
